3-2.sample 프로젝트를 로그를 살펴보자

3월 05, 2016 1:38:55 오전 org.apache.tomcat.util.digester.SetPropertiesRule begin

경고: [SetPropertiesRule]{Server/Service/Engine/Host/Context} Setting property 'source' to 'org.eclipse.jst.jee.server:ex01.sample' did not find a matching property.

3월 05, 2016 1:38:55 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Server version: Apache Tomcat/8.0.24

3월 05, 2016 1:38:55 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Server built: Jul 1 2015 20:19:55 UTC

3월 05, 2016 1:38:55 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Server number: 8.0.24.0

3월 05, 2016 1:38:55 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: OS Name: Windows 7

3월 05, 2016 1:38:55 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: OS Version: 6.1

3월 05, 2016 1:38:55 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Architecture: x86

3월 05, 2016 1:38:55 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Java Home: C:\eGovFrame-3.5.1\bin\jdk1.7.0_80\jre

3월 05, 2016 1:38:55 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: JVM Version: 1.7.0_80-b15

3월 05, 2016 1:38:55 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: JVM Vendor: Oracle Corporation

3월 05, 2016 1:38:55 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: CATALINA_BASE: C:\eGovFrame-3.5.1\workspace.test\.metadata\.plugins\org.eclipse.wst.server.core\tmp0

3월 05, 2016 1:38:55 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: CATALINA_HOME: C:\eGovFrame-3.5.1\bin\apache-tomcat-8.0.24

3월 05, 2016 1:38:55 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Command line argument: -Dcatalina.base=C:\eGovFrame-3.5.1\workspace.test\.metadata\.plugins\org.eclipse.wst.server.core\tmp0

3월 05, 2016 1:38:55 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Command line argument: -Dcatalina.home=C:\eGovFrame-3.5.1\bin\apache-tomcat-8.0.24

3월 05, 2016 1:38:55 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Command line argument: -Dwtp.deploy=C:\eGovFrame-3.5.1\workspace.test\.metadata\.plugins\org.eclipse.wst.server.core\tmp0\wtpwebapps

3월 05, 2016 1:38:55 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Command line argument: -Djava.endorsed.dirs=C:\eGovFrame-3.5.1\bin\apache-tomcat-8.0.24\endorsed

3월 05, 2016 1:38:55 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Command line argument: -Dfile.encoding=UTF-8

3월 05, 2016 1:38:55 오전 org.apache.catalina.core.AprLifecycleListener lifecycleEvent

정보: The APR based Apache Tomcat Native library which allows optimal performance in production environments was not found on the java.library.path: C:\eGovFrame-3.5.1\bin\jdk1.7.0_80\bin;C:\Windows\Sun\Java\bin;C:\Windows\system32;C:\Windows;C:\Windows\system32;C:\Windows;C:\Windows\System32\Wbem;C:\Windows\System32\WindowsPowerShell\v1.0\;C:\Program Files\Bandizip\7z;.

3월 05, 2016 1:38:55 오전 org.apache.coyote.AbstractProtocol init

정보: Initializing ProtocolHandler ["http-nio-8080"]

3월 05, 2016 1:38:55 오전 org.apache.tomcat.util.net.NioSelectorPool getSharedSelector

정보: Using a shared selector for servlet write/read

3월 05, 2016 1:38:55 오전 org.apache.coyote.AbstractProtocol init

정보: Initializing ProtocolHandler ["ajp-nio-8009"]

3월 05, 2016 1:38:55 오전 org.apache.tomcat.util.net.NioSelectorPool getSharedSelector

정보: Using a shared selector for servlet write/read

3월 05, 2016 1:38:55 오전 org.apache.catalina.startup.Catalina load

정보: Initialization processed in 736 ms

3월 05, 2016 1:38:56 오전 org.apache.catalina.core.StandardService startInternal

정보: Starting service Catalina

3월 05, 2016 1:38:56 오전 org.apache.catalina.core.StandardEngine startInternal

정보: Starting Servlet Engine: Apache Tomcat/8.0.24

3월 05, 2016 1:38:56 오전 org.apache.catalina.util.SessionIdGeneratorBase createSecureRandom

정보: Creation of SecureRandom instance for session ID generation using [SHA1PRNG] took [125] milliseconds.

3월 05, 2016 1:38:59 오전 org.apache.jasper.servlet.TldScanner scanJars

정보: At least one JAR was scanned for TLDs yet contained no TLDs. Enable debug logging for this logger for a complete list of JARs that were scanned but no TLDs were found in them. Skipping unneeded JARs during scanning can improve startup time and JSP compilation time.

3월 05, 2016 1:38:59 오전 org.apache.catalina.core.ApplicationContext log

정보: No Spring WebApplicationInitializer types detected on classpath

3월 05, 2016 1:38:59 오전 org.apache.catalina.core.ApplicationContext log

정보: Initializing Spring root WebApplicationContext

2016-03-05 01:38:59,705 INFO [org.springframework.web.context.ContextLoader] Root WebApplicationContext: initialization started

2016-03-05 01:38:59,893 INFO [org.springframework.web.context.support.XmlWebApplicationContext] Refreshing Root WebApplicationContext: startup date [Sat Mar 05 01:38:59 KST 2016]; root of context hierarchy

2016-03-05 01:38:59,971 INFO [org.springframework.beans.factory.xml.XmlBeanDefinitionReader] Loading XML bean definitions from file [C:\eGovFrame-3.5.1\workspace.test\.metadata\.plugins\org.eclipse.wst.server.core\tmp0\wtpwebapps\ex01.sample\WEB-INF\classes\egovframework\spring\context-aspect.xml]

2016-03-05 01:39:00,143 INFO [org.springframework.beans.factory.xml.XmlBeanDefinitionReader] Loading XML bean definitions from file [C:\eGovFrame-3.5.1\workspace.test\.metadata\.plugins\org.eclipse.wst.server.core\tmp0\wtpwebapps\ex01.sample\WEB-INF\classes\egovframework\spring\context-common.xml]

2016-03-05 01:39:00,362 INFO [org.springframework.beans.factory.xml.XmlBeanDefinitionReader] Loading XML bean definitions from file [C:\eGovFrame-3.5.1\workspace.test\.metadata\.plugins\org.eclipse.wst.server.core\tmp0\wtpwebapps\ex01.sample\WEB-INF\classes\egovframework\spring\context-datasource.xml]

2016-03-05 01:39:00,393 INFO [org.springframework.beans.factory.xml.XmlBeanDefinitionReader] Loading XML bean definitions from file [C:\eGovFrame-3.5.1\workspace.test\.metadata\.plugins\org.eclipse.wst.server.core\tmp0\wtpwebapps\ex01.sample\WEB-INF\classes\egovframework\spring\context-idgen.xml]

2016-03-05 01:39:00,409 INFO [org.springframework.beans.factory.xml.XmlBeanDefinitionReader] Loading XML bean definitions from file [C:\eGovFrame-3.5.1\workspace.test\.metadata\.plugins\org.eclipse.wst.server.core\tmp0\wtpwebapps\ex01.sample\WEB-INF\classes\egovframework\spring\context-mapper.xml]

2016-03-05 01:39:00,440 INFO [org.springframework.beans.factory.xml.XmlBeanDefinitionReader] Loading XML bean definitions from file [C:\eGovFrame-3.5.1\workspace.test\.metadata\.plugins\org.eclipse.wst.server.core\tmp0\wtpwebapps\ex01.sample\WEB-INF\classes\egovframework\spring\context-properties.xml]

2016-03-05 01:39:00,456 INFO [org.springframework.beans.factory.xml.XmlBeanDefinitionReader] Loading XML bean definitions from file [C:\eGovFrame-3.5.1\workspace.test\.metadata\.plugins\org.eclipse.wst.server.core\tmp0\wtpwebapps\ex01.sample\WEB-INF\classes\egovframework\spring\context-sqlMap.xml]

2016-03-05 01:39:00,456 INFO [org.springframework.beans.factory.xml.XmlBeanDefinitionReader] Loading XML bean definitions from file [C:\eGovFrame-3.5.1\workspace.test\.metadata\.plugins\org.eclipse.wst.server.core\tmp0\wtpwebapps\ex01.sample\WEB-INF\classes\egovframework\spring\context-transaction.xml]

2016-03-05 01:39:00,502 INFO [org.springframework.beans.factory.xml.XmlBeanDefinitionReader] Loading XML bean definitions from file [C:\eGovFrame-3.5.1\workspace.test\.metadata\.plugins\org.eclipse.wst.server.core\tmp0\wtpwebapps\ex01.sample\WEB-INF\classes\egovframework\spring\context-validator.xml]

2016-03-05 01:39:01,221 DEBUG [egovframework.rte.fdl.cmmn.aspect.ExceptionTransfer] count of ExceptionHandlerServices = 2

2016-03-05 01:39:01,332 INFO [org.springframework.jdbc.datasource.embedded.EmbeddedDatabaseFactory] Creating embedded database 'dataSource'

2016-03-05 01:39:01,691 INFO [org.springframework.jdbc.datasource.init.ScriptUtils] Executing SQL script from class path resource [db/sampledb.sql]

2016-03-05 01:39:01,707 INFO [org.springframework.jdbc.datasource.init.ScriptUtils] Executed SQL script from class path resource [db/sampledb.sql] in 16 ms.

2016-03-05 01:39:02,363 DEBUG [egovframework.rte.fdl.property.impl.EgovPropertyServiceImpl] [Properties Service] 프로퍼티 key = pageUnit, 값 = 10 은 이 설정파일에 정의되어 있습니다.

2016-03-05 01:39:02,363 DEBUG [egovframework.rte.fdl.property.impl.EgovPropertyServiceImpl] [Properties Service] 프로퍼티 key = pageSize, 값 = 10 은 이 설정파일에 정의되어 있습니다.

2016-03-05 01:39:02,379 INFO [org.springmodules.validation.commons.DefaultValidatorFactory] Loading validation configurations from [ServletContext resource [/WEB-INF/config/egovframework/validator/validator-rules.xml],ServletContext resource [/WEB-INF/config/egovframework/validator/validator.xml]]

2016-03-05 01:39:02,567 INFO [org.springframework.web.context.ContextLoader] Root WebApplicationContext: initialization completed in 2862 ms

3월 05, 2016 1:39:02 오전 org.apache.catalina.core.ApplicationContext log

정보: Initializing Spring FrameworkServlet 'action'

2016-03-05 01:39:02,598 INFO [org.springframework.web.servlet.DispatcherServlet] FrameworkServlet 'action': initialization started

2016-03-05 01:39:02,598 INFO [org.springframework.web.context.support.XmlWebApplicationContext] Refreshing WebApplicationContext for namespace 'action-servlet': startup date [Sat Mar 05 01:39:02 KST 2016]; parent: Root WebApplicationContext

2016-03-05 01:39:02,598 INFO [org.springframework.beans.factory.xml.XmlBeanDefinitionReader] Loading XML bean definitions from ServletContext resource [/WEB-INF/config/egovframework/springmvc/dispatcher-servlet.xml]

2016-03-05 01:39:02,943 INFO [org.springframework.web.servlet.mvc.method.annotation.RequestMappingHandlerMapping] Mapped "{[/updateSample.do],methods=[],params=[],headers=[],consumes=[],produces=[],custom=[]}" onto public java.lang.String egovframework.example.sample.web.EgovSampleController.updateSample(egovframework.example.sample.service.SampleDefaultVO,egovframework.example.sample.service.SampleVO,org.springframework.validation.BindingResult,org.springframework.ui.Model,org.springframework.web.bind.support.SessionStatus) throws java.lang.Exception

2016-03-05 01:39:02,943 INFO [org.springframework.web.servlet.mvc.method.annotation.RequestMappingHandlerMapping] Mapped "{[/deleteSample.do],methods=[],params=[],headers=[],consumes=[],produces=[],custom=[]}" onto public java.lang.String egovframework.example.sample.web.EgovSampleController.deleteSample(egovframework.example.sample.service.SampleVO,egovframework.example.sample.service.SampleDefaultVO,org.springframework.web.bind.support.SessionStatus) throws java.lang.Exception

2016-03-05 01:39:02,943 INFO [org.springframework.web.servlet.mvc.method.annotation.RequestMappingHandlerMapping] Mapped "{[/egovSampleList.do],methods=[],params=[],headers=[],consumes=[],produces=[],custom=[]}" onto public java.lang.String egovframework.example.sample.web.EgovSampleController.selectSampleList(egovframework.example.sample.service.SampleDefaultVO,org.springframework.ui.ModelMap) throws java.lang.Exception

2016-03-05 01:39:02,943 INFO [org.springframework.web.servlet.mvc.method.annotation.RequestMappingHandlerMapping] Mapped "{[/addSample.do],methods=[GET],params=[],headers=[],consumes=[],produces=[],custom=[]}" onto public java.lang.String egovframework.example.sample.web.EgovSampleController.addSampleView(egovframework.example.sample.service.SampleDefaultVO,org.springframework.ui.Model) throws java.lang.Exception

2016-03-05 01:39:02,943 INFO [org.springframework.web.servlet.mvc.method.annotation.RequestMappingHandlerMapping] Mapped "{[/addSample.do],methods=[POST],params=[],headers=[],consumes=[],produces=[],custom=[]}" onto public java.lang.String egovframework.example.sample.web.EgovSampleController.addSample(egovframework.example.sample.service.SampleDefaultVO,egovframework.example.sample.service.SampleVO,org.springframework.validation.BindingResult,org.springframework.ui.Model,org.springframework.web.bind.support.SessionStatus) throws java.lang.Exception

2016-03-05 01:39:02,943 INFO [org.springframework.web.servlet.mvc.method.annotation.RequestMappingHandlerMapping] Mapped "{[/updateSampleView.do],methods=[],params=[],headers=[],consumes=[],produces=[],custom=[]}" onto public java.lang.String egovframework.example.sample.web.EgovSampleController.updateSampleView(java.lang.String,egovframework.example.sample.service.SampleDefaultVO,org.springframework.ui.Model) throws java.lang.Exception

2016-03-05 01:39:03,005 INFO [org.springframework.web.servlet.handler.SimpleUrlHandlerMapping] Mapped URL path [/cmmn/validator.do] onto handler of type [class org.springframework.web.servlet.mvc.ParameterizableViewController]

2016-03-05 01:39:03,052 INFO [org.springframework.web.servlet.DispatcherServlet] FrameworkServlet 'action': initialization completed in 454 ms

3월 05, 2016 1:39:03 오전 org.apache.coyote.AbstractProtocol start

정보: Starting ProtocolHandler ["http-nio-8080"]

3월 05, 2016 1:39:03 오전 org.apache.coyote.AbstractProtocol start

정보: Starting ProtocolHandler ["ajp-nio-8009"]

3월 05, 2016 1:39:03 오전 org.apache.catalina.startup.Catalina start

정보: Server startup in 7085 ms

2016-03-05 01:39:04,750 DEBUG [egovframework.rte.psl.orm.ibatis.SqlMapClientTemplate] Opened SqlMapSession [com.ibatis.sqlmap.engine.impl.SqlMapSessionImpl@1782068] for iBATIS operation

2016-03-05 01:39:04,750 DEBUG [egovframework.rte.psl.orm.ibatis.SqlMapClientTemplate] Obtained JDBC Connection [Transaction-aware proxy for target Connection from DataSource [org.springframework.jdbc.datasource.SimpleDriverDataSource@1e8d906]] for iBATIS operation

2016-03-05 01:39:04,782 DEBUG [egovframework.rte.psl.orm.ibatis.SqlMapClientTemplate] Opened SqlMapSession [com.ibatis.sqlmap.engine.impl.SqlMapSessionImpl@18e2c4e] for iBATIS operation

2016-03-05 01:39:04,782 DEBUG [egovframework.rte.psl.orm.ibatis.SqlMapClientTemplate] Obtained JDBC Connection [Transaction-aware proxy for target Connection from DataSource [org.springframework.jdbc.datasource.SimpleDriverDataSource@1e8d906]] for iBATIS operation

3월 04, 2016 10:16:26 오전 org.apache.tomcat.util.digester.SetPropertiesRule begin

경고: [SetPropertiesRule]{Server/Service/Engine/Host/Context} Setting property 'source' to 'org.eclipse.jst.jee.server:ex01.sample' did not find a matching property.

===> 환경정보

3월 04, 2016 10:16:26 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Server version: Apache Tomcat/8.0.24 ---> 서버 버전

3월 04, 2016 10:16:26 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Server built: Jul 1 2015 20:19:55 UTC ---> 서버빌드

3월 04, 2016 10:16:26 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Server number: 8.0.24.0 ---> 서버 번호(버전)

3월 04, 2016 10:16:26 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: OS Name: Windows 7 ---> OS 이름

3월 04, 2016 10:16:26 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: OS Version: 6.1 ---> OS 버전

3월 04, 2016 10:16:26 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Architecture: x86 ---> OS bit 정보

3월 04, 2016 10:16:26 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Java Home: C:\eGovFrame-3.5.1\bin\jdk1.7.0_80\jre ---> 자바 환경변수

3월 04, 2016 10:16:26 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: JVM Version: 1.7.0_80-b15 ---> 자바 버전

3월 04, 2016 10:16:26 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: JVM Vendor: Oracle Corporation ---> 자바 벤더

3월 04, 2016 10:16:26 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: CATALINA_BASE: C:\eGovFrame-3.5.1\workspace.test\.metadata\.plugins\org.eclipse.wst.server.core\tmp0 ---> 톰켓 웹베이스

3월 04, 2016 10:16:26 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: CATALINA_HOME: C:\eGovFrame-3.5.1\bin\apache-tomcat-8.0.24 ---> 톰켓 환경변수

===> 구동정버

3월 04, 2016 10:16:26 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Command line argument: -Dcatalina.base=C:\eGovFrame-3.5.1\workspace.test\.metadata\.plugins\org.eclipse.wst.server.core\tmp0

---> 톰켓 웹베이스

3월 04, 2016 10:16:26 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Command line argument: -Dcatalina.home=C:\eGovFrame-3.5.1\bin\apache-tomcat-8.0.24 ---> 톰켓 환경변수

3월 04, 2016 10:16:26 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Command line argument: -Dwtp.deploy=C:\eGovFrame-3.5.1\workspace.test\.metadata\.plugins\org.eclipse.wst.server.core\tmp0\wtpwebapps

---> 배포 위치

3월 04, 2016 10:16:26 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Command line argument: -Djava.endorsed.dirs=C:\eGovFrame-3.5.1\bin\apache-tomcat-8.0.24\endorsed ---> 실제 없는 경로(endoresed)

3월 04, 2016 10:16:26 오전 org.apache.catalina.startup.VersionLoggerListener log

정보: Command line argument: -Dfile.encoding=UTF-8 ---> 인코딩설정

3월 04, 2016 10:16:26 오전 org.apache.catalina.core.AprLifecycleListener lifecycleEvent

정보: The APR based Apache Tomcat Native library which allows optimal performance in production environments was not found on the java.library.path: C:\eGovFrame-3.5.1\bin\jdk1.7.0_80\bin;C:\Windows\Sun\Java\bin;C:\Windows\system32;C:\Windows;C:\Windows\system32;C:\Windows;C:\Windows\System32\Wbem;C:\Windows\System32\WindowsPowerShell\v1.0\;C:\Program Files\Bandizip\7z;.

---> path 경로에 환경변수가 지정되지 않았다.(그래도 문제없음)

3월 04, 2016 10:16:26 오전 org.apache.coyote.AbstractProtocol init

정보: Initializing ProtocolHandler ["http-nio-8080"] ---> ProtocolHandler 설정 : http 8080

3월 04, 2016 10:16:26 오전 org.apache.tomcat.util.net.NioSelectorPool getSharedSelector

정보: Using a shared selector for servlet write/read ---> 서블릿 쓰기/읽기를 위해 공유된 선택기 사용(http)

3월 04, 2016 10:16:26 오전 org.apache.coyote.AbstractProtocol init

정보: Initializing ProtocolHandler ["ajp-nio-8009"] ---> ProtocolHandler 설정 : ajp 8080

3월 04, 2016 10:16:26 오전 org.apache.tomcat.util.net.NioSelectorPool getSharedSelector

정보: Using a shared selector for servlet write/read ---> 서블릿 쓰기/읽기를 위해 공유된 선택기 사용(ajp)

3월 04, 2016 10:16:26 오전 org.apache.catalina.startup.Catalina load

정보: Initialization processed in 778 ms ---> 서비스 초기화

3월 04, 2016 10:16:26 오전 org.apache.catalina.core.StandardService startInternal

정보: Starting service Catalina ---> 서비스 시작

3월 04, 2016 10:16:26 오전 org.apache.catalina.core.StandardEngine startInternal

정보: Starting Servlet Engine: Apache Tomcat/8.0.24 ---> 서블릿 엔진 시작

3월 04, 2016 10:16:28 오전 org.apache.jasper.servlet.TldScanner scanJars

정보: At least one JAR was scanned for TLDs yet contained no TLDs. Enable debug logging for this logger for a complete list of JARs that were scanned but no TLDs were found in them. Skipping unneeded JARs during scanning can improve startup time and JSP compilation time.

---> jar 라이브러리를 스켄하여 컨테이너에 포함할 것이 없음을 확인

3월 04, 2016 10:16:28 오전 org.apache.catalina.core.ApplicationContext log

정보: No Spring WebApplicationInitializer types detected on classpath

3월 04, 2016 10:16:28 오전 org.apache.catalina.core.ApplicationContext log

정보: Initializing Spring root WebApplicationContext

===> Spring Web Application 초기화
